Quanlity100 WN573HX1 Dual-Band AX WiFi6 Mesh Router with POE

Professional Outdoor Router/AP/Repeater, Enjoy Super-Speed WiFi6 Anytime &amp; Anywhere<br> <br> High-performance outdoor router/AP/repeater specially designed for outdoor use: Robust weatherproof case and 15kV ESD protection ensure continuous operation and stable connection under harsh outdoor conditions; The 4 x 8dBi omnidirectional fiberglass tube antennas feature high strength and high precision, a long service life and excellent wireless performance; Supports IEEE 802.11 ax/ac/a/n/g/b standards, and provides blazing-fast Internet speeds of 1800Mbps (2.4GHz 574Mbps+5GHz 1201Mbps); Supports MU-MIMO and Beamforming technology, allowing up to 128 devices to be connected simultaneously in a wider range.<br> <br> How to install antennas and Ethernet cable?<br> ①Pass the RJ45 cable through the waterproof connector cover.<br> ②Screw the waterproof seal into the waterproof connector bracket.<br> ③Pass the RJ45 cable through the waterproof connector bracket, and screw the waterproof connector bracket into the cover.<br> ④Put the waterproof sealing ring on the waterproof connector bracket.<br> ⑤Connect the RJ45 cable to WAN/LAN port.<br> ⑥Screw the connecting cable into the 2.4G and 5G antenna connector and screw up the connector.<br> Note: The PoE converter is not waterproof, please install it indoors. Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m/328ft.<br> <br> How to install the product on a column?<br> ①Stick two silicone pads on the bracket and post respectively.<br> ②Thread the cable ties through the fixing point of the bracket.<br> ③Fix the product to the post with cable ties.<br> <br> Fiberglass Tube High Gain Antennas<br> 4 x 8dBi omnidirectional antennas are covered by strong fiberglass tube, expanding signal coverage and withstanding harsh conditions, providing superior WiFi performance and longer service life.<br> <br> IP67 Waterproof Enclosure<br> Equipped with an IP67 enclosure with excellent dustproof and waterproof capabilities, this product can operate normally in rainy days, snowy days, thunderstorms, sandstorms and other severe weather.<br> <br> PoE Power Supply<br> Both active and passive PoE are supported. You can install the corresponding PoE converter according to your needs. Passive PoE converter included.<br> <br> 574Mbps on 2.4G &amp; 1201Mbps on 5G<br> Dual band AX1800 provides smoother online surfing experience and stronger anti-interference capability. 2.4G band is commendable for web browsing and social media use, while 5G band is ideal for video streaming or gaming.<br> <br> High Power Amplifiers<br> Dual integrated signal boosters efficiently strengthen the wireless performance. The PA(power amplifier) increases the power output while the LNA(low-noise amplifier) minimizes additional noises and increases the wireless signal. <br> <br> Advanced WiFi Safeguard<br> WPA2-PSK &amp; WPA2/WPA3-MIX wireless security protocols are supported, fully protecting your private information and keeping your WiFi connection secure at all times.<br> <br> Specification<br> - Model: WL-WN573HX1<br> - Product Size(without antennas): 24x24x7cm/9.4x9.4x2.8in<br> - PoE Converter Size: 4.4x3.7x2.2cm/1.7x1.5x0.9in<br> - Length: Antennas - 40cm/15.7in; Ethernet Cable - 100cm/39.4in; Power Adapter Cable - 130cm/51.2in<br> - Product Weight(without antennas): 1109g/39.1oz<br> - Standard: IEEE 802.11 ax/ac/a/n/g/b<br> - Frequency Band/Speed: 2.4GHz(574Mbps)+5GHz(1201Mbps)<br> - Wireless Security: WPA2-PSK, WPA2/WPA3-MIX<br> - Antennas: 4 x 8dBi Omnidirectional Antennas<br> - PAIR/RESET LED: Blue<br> - PoE Converter Status LED: Green<br> <br> Features<br> - Robust weatherproof case, IP67 waterproof rating and built-in lightning arrester (15kV ESD) withstands harsh outdoor conditions.<br> - Supports 802.3 AT/AF active PoE and passive PoE to supply power.<br> - Fiberlass tube antennas for high precision, corrosion resistance, long life, strong wind resistance.<br> - 4x8dBi detachable omnidirectional external antennas provide excellent wireless performance.<br> - Supports dual band(2.4G 573Mbps+5G 1201Mbps) with combined speeds of up to 1800Mbps.<br> - Mesh technology makes you enjoy seamless roaming throughout the house with a single network name and password.<br> - Complies with IEEE 802.11 ax/ac/a/n/g/b standards.<br> - Supports Mesh/AP/Router/Repeater/AP+Repeater modes.<br> - Encryption type:WPA2-PSK, WPA3/WPA2-MIX.<br> <br> Warm Tips<br> ①The PoE converter is not waterproof, please install it indoors.<br> ②Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m/328ft.<br> ③Please install the product 2-3 meters above the ground for better performance.<br> ④Under the mesh mode, WN573HX1 ONLY supports interconnection with WN531AX2, WN583AX1 and WN573HX1.<br> <br> In the Box<br> 1 x Wi-Fi6 Outdoor Mesh Router/AP/Repeater<br> 4 x Omni Antennas<br> 4 x Cable Ties<br> 1 x Ethernet Cable Connectors<br> 1 x Quick Installation<br> 1 x Wrench<br> 2 x Silicone Pads<br> <br> Several Screws<br> Passive PoE(Optional):<br> 1 x 54V Power Adapter<br> 1 x PoE Converter<br> 1 x Ethernet Cable

• Robust weatherproof case, IP67 waterproof rating and built-in lightning arrester (15kV ESD) withstand harsh outdoor conditions.
• Supports 802.3 AT/AF active PoE and passive PoE to supply power, allowing for flexible installation where power outlets are not available.
• Fiberglass tube antennas provide high precision, corrosion resistance, long life, and strong wind resistance for superior outdoor performance.
• 4x8dBi detachable omnidirectional external antennas deliver excellent wireless coverage and performance.
• Supports dual band (2.4G 573Mbps+5G 1201Mbps) with combined speeds of up to 1800Mbps for smooth online activities, even outdoors.
• Mesh technology enables seamless roaming throughout the coverage area with a single network name and password.
• Complies with the latest IEEE 802.11 ax/ac/a/n/g/b standards for reliable and future-proof connectivity.
• Supports versatile Mesh/AP/Router/Repeater/AP+Repeater modes to meet various outdoor connectivity needs.
• Provides secure wireless encryption with WPA2-PSK and WPA3/WPA2-MIX protocols.
