Goulds / Xylem J10S 1 HP Shallow Well Jet Pump, 115/230 V Capacitor Start

Goulds J10S1 HP Shallow Well Jet Pump, 115/230 V Capacitor StartFEATURES:Compact: Design has an integral shallow well adapter built infto the casing, which eliminates the need for a separate shallow well adapter.SERVICEABLE:Back pullout design allows disassembly of pump for service without disturbing piping.Two compartment motor for easy access to motor wiring and replaceable components.Nozzle clean out plug in pump case.Corrosion resistant, engineered plastic tubing and fittings are easily removed for cleaning. Premium O-ringImpeller: F.D.A. compliant, glass filled Noryl?. Corrosion and abrasion resistant.Diffuser (Guidevane): Bolt down diffuser provides positive alignment with impeller. Diffuser also has stainless wear ring for extended performance in abrasive conditions. F.D.A. compliant, injection molded, food grade, glass filled Lexan? for durability and abrasion resistance.Tubing and Fittings: F.D.A. compliant engineered plastic is corrosion and U.V. resistant.Powered for Continuous Operation: Pump ratings are within the motor manufacturer's recommended working limits. Can be operated continuously without damage.Corrosion Resistant: Electro-coated paint process is applied inside and out, then baked on.Protected Mechanical Seal: Special diaphragm design retains water in the casing at all times to ensure the mechanical seal can never run dry.Excellent Air Handling Ability: After initial priming the pump has the ability to re-prime itself even when air gets into the system. Pumping resumes once the water level rises above the foot valve.Specifically designed for the following uses: Homes, Cottages & Booster servicePump SPECIFICATIONS:Pipe connections: 1.25" NPT suction and 1" NPT dischargePressure switch: AS4 preset (30-50 PSI).MOTOR:NEMA standard60 Hz1 HP, 115/230 V capacitor startSingle phase3500 RPMBuilt-in overload with automatic resetStainless steel shaftRotation: clockwise when viewed from motor endUL778 listedMAXIMUM TEMPERATURE: 140?F.SYSTEM COMPONENTS:Basic Pump Unit: Includes pump with integral shallow well jet (nozzle and venturi), motor, pressure switch and tubing.DIMENSIONS AND WEIGHTS:Length: 18.75 Inch.Width: 9.88 Inch.Height: 8.75 Inch."L" Max: 10 InchSee all sketch images for more details:

• 1 HP Motor - 115 or 220 volt service

• Goulds / Xylem JS+ Series Blue Shallow Well Jet Pump

• Pipe connections: 1 1/4 inch. NPT suction, 1 inch. NPT discharge

• Pressure switch: AS4FX preset (30-50 PSI)

• Great For Homes, Cottages, Booster Service & Light irrigation system

• Pressure regulator included.
